Accessories - Thomashilfen Swifty 2 Gebrauchsanweisung

Instructions for Use – Swifty 2

Accessories

Remarks: Installation information is found in the Instructions for Use, which are enclosed with the accessory. If the copy
of the Instructions for Use is missing, you can download one from www.thomashilfen.de. The assembly / disassembly of
the accessories is done with standard tools.
Abduction block (Fig. 31)
The abduction block helps spread the legs at the hip joint and position the thighs. It goes at the knees and prevents the
legs from being crossed.
Grip rail (Fig. 32)
The grip rail is affixed by the user and provides extra stability when sitting.
Tray (Fig. 33)
The tray consists of a firm vent tray which is attached in front of the user. On the tray various therapeutic activities can
be done.
Lateral trunk supports, rigid (Fig. 34)
The rigid lateral trunk supports are affixed in the position needed on the back section and support the user's trunk on
the left and right sides. As a result, control of the trunk is improved and supported. The user can still move their arms.
Lateral trunk supports, flexible (Fig. 35)
The lateral trunk supports are affixed in the position needed on the back plate and support the user to the left and right
of the trunk. As a result, control of the trunk is improved and supported. The user can still move their arms. Both trunk
supports can be bent slightly forward and are connected with a belt. In this way the user has extra support at the front.
Frame padding (Fig. 36)
The frame padding is put along the lateral side posts of the push bar. They go a long way to protect fidgety users from
injuring themselves on the rolling chassis.
Seat minimizer set (Fig. 37)
The seat minimizer set reduces the seat depth and width thereby extending the use period of the seat. It consists of four
parts: Head pillow, seat wedge, lateral seat padding (right), lateral seat padding (left)
Seat width minimizer (Fig. 38)
Seat width minimizers are put on the left and right of the seat side plates. They reduce the seat width and offer firm
support for slim users thereby extending the seat's use period.
Lateral seat guide padding (Fig. 39)
The lateral seat guide padding covers the seat's metal side pieces and protects the user.
2-point pelvic belt (Fig. 40)
The 2-point pelvic belt is a simple positioning aid to stabilise the user's pelvic area. It goes horizontally across the user's
groin.
4-point pelvic belt(Fig. 41)
The four-point pelvic belt is a simple positioning aid to stabilise the user's pelvic area. It goes horizontally across the
user's groin and is also fastened at each side under the seat.
Crotch strap (Fig. 42)
The crotch strap can only be used in combination with an H-belt or pelvic belt. It gives the user extra stability in the
pelvic area and prevents the user from slipping out of the belts.
29
2021-04
