Power supply
Mains voltage
Mains frequency
Power consumption ( of VLR.20d)
Max. current output
only for US and CA models:
- Weak inductive / ohms
- Motor load
Fuse (dimensions 6.3x32mm)
Power outage relay
Relay de-energizes if the power fails
Control
Type
Input resistance
Manual operation
Knob
Housing
Plastic housing with screw on lid
Dimensions (l×w×h)
Weight (unpacked)
Ambient climate
Operating temperature range
Storage temperature range
Relative humidity
Fancom advises 2-wire connection of Fancom fans. If the fans are connected parallel, heat production
per fan may increase (causing a shortened working life). Fancom therefore advises not to parallel switch
more than three fans. See connection diagrams.
230Vac (-10% +6%)
max. 20 FLA
max. 17FLA
Very Fast Acting 30A - 250V
30Vac/60Vdc - max. 2A
10-0Vdc/0-10Vdc
for 0-100% if the 10-0Vdc control fails
300×240×140mm (11.8×9.4×5.5 inches)
2.55kg(5.6lbs)
0C to +40C (32F to 104F)
-10C to 50C (14F to 112F)
< 95%, uncondensed
Gndf
50-60Hz
3.5VA
20A
120k
IP54
