You can avoid potential false triggers due to temperature and motion disturbances in front of the
camera by not aiming it at a heat source or nearby tree branches or brush (especially on windy
days).
11.

Downloading the photos/videos

To download your photos/videos to a computer, first make sure the camera power switch is in
the OFF position. Connect the supplied cable to the camera's USB port, then directly to a main
USB port on your computer.
12.

Technical specifications

Image sensor
Lens
IR flash
LCD display
Memory card
Picture resolution
Video resolution
Video length
PIR sensing distance
PIR sensing angle
PIR sensitivity
Operation mode
Audio
Trigger time
Fixed time
Time stamp
Series photos
Power supply
Stand-by current
Interface
# PIE 1010 – indice A
5MP color CMOS
F=3.0, FOV (field of view)=45°
940 nm – range up to 65 feet / 20 m
2" TFT color
from 20MB to 32GB
12MP=4032x3024, 8MP=3264x2448, 5MP=2560x1920
1080P (30fps), 720P (30fps), VGA (30fps)
programmable - 10s, 20s, 30s, 60s
65 feet / 20 m (below 77°F/25°C at the normal level)
45°-50°
adjustable (High/Medium/Low)
Camera, Video, Camera + Video (first take a picture then a video)
videos with audio recording
0.6 second
ON/OFF
date, time, temperature, moon phase, battery level, camera serial
number
programmable - 1, 2, 3
8xAA (LR06) or solar power supply
<0.35mA (<6mAh/day)
USB connector, SD card slot and external DC power connector
