Technical Information
Controller Outline
Controller Outline
The outline dimensions for the TwisTorr 74 FS AG Rack
Controllers are shown in the following figure.
The TwisTorr controller can be used as a bench unit or as a rack module, in any
NOTE
case it must be positioned so that free air can flow through the housing holes.
Figure 5
212/300
1.5 [0.06]
244.0 [9.61]
Controller outline
TwisTorr 74 FS AG Rack Controller User Manual / 87-901-055-01
9.4 [0.37]
Dimensions: mm [inches]
106.4 [4.19]
91.4 [3.60]
=
=
LS
R1
AG
R2
VACUUM TECHNOLOGIES
COUNTERS
MEASURES
increase
next
menu
previous
decrease
LOW SPEED
START/STOP
TwisTorr 74 FS AG
Turbo-V 301-AG
