16 Commissioning and adjustments:

How to adjust your system perfectly to your needs
Before commissioning your air curtain system, you must ensure that all water installations and
electrical installations have been carried out correctly.
As default the heating element connections for hot water operation are located on the right-hand
side. They can also be located on the left-hand side or on top of the system . Flow/return runs are
marked (flow in red, return flow in blue).
As default the cable glands for the motor electrical connections are located on the left-hand side.
They can also be located on the right-hand side or on top of the system.
Stand 30.10.2019
To avoid the risk of electric shock, the heating must be connected before
connecting the electricity. Check that the system is de-energized before
connecting the heating!
For systems with integrated thermostatic control valve, the valve is NOT
"sealed" when screwed in. The connection is only sealed when screwed
together after pipe installation!
All water and electrical installations must be performed by specialist
companies (plumbers, electricians). Teddington Luftschleieranlagen GmbH
can otherwise not assume any warranty (see chapter "Safety").
Only connect heating pipes with appropriate tools, so that connections
(pipes, heat exchanger connections) are secured to prevent twisting.
Before commissioning all pipes must undergo an expert pressure inspection.
Similarly, all electrical cables must be inspected! Incorrect connection can lead
to danger to life! Important: no safety parts, covers and grounding conductor
connections may be removed.
Measure the fan motor's electrical input and compare it with the electrical
input data on the model label.
