Fehler - Störungen
• Erdschluss
Die Versorgungsspannung bricht zusammen
und die Sicherheitskontakte werden über eine
elektronische Sicherung geöffnet. Nach
Wegfall der Störungsursache und Abschalten
der Versorgungsspannung für ca. 1 Minute ist
das Gerät wieder betriebsbereit.
• Fehlfunktionen der Kontakte: Bei verschweiß-
ten Kontakten ist nach Öffnen des Eingangs-
kreises keine neue Aktivierung möglich.
• LED "POWER" leuchtet nicht: Kurz-schluss
oder Versorgungsspannung fehlt.
• Abbruch der Verzögerungszeit
Im Fehlerfall können die rückfallverzögerten
Kontakte vor Ablauf der Verzögerungszeit
öffnen.
Technische Daten
Elektrische Daten
Versorgungsspannung U
B
Spannungstoleranz
Leistungsaufnahme bei U
B
Frequenzbereich
Restwelligkeit
Spannung und Strom an
Eingangskreis
U
DC:
B
U
AC/DC:
B
Startkreis
Rückführkreis
Anzahl der Ausgangskontakte
Sicherheitskontakte (S)
unverzögert
verzögert
Hilfskontakt (Ö)
Gebrauchskategorie nach
EN 60947-4-1
EN 60947-5-1(DC13:
6 Schaltspiele/Min.)
Kontaktmaterial
Kontaktabsicherung extern
EN 60947-5-1 (I
= 1 kA)
K
Schmelzsicherung flink
Schmelzsicherung träge
Sicherungsautomat
Charakteristik
Max. Gesamtleitungswiderstand R
Eingangskreise
einkanalig DC
einkanalig AC
zweikanalig mit
Querschlusserkennung DC
zweikanalig mit
Querschlusserkennung AC
zweikanalig ohne
Querschlusserkennung DC
zweikanalig ohne
Querschlusserkennung AC
Sicherheitstechnische Kenndaten
der Sicherheitsausgänge
PL nach EN ISO 13849-1
unverzögert
verzögert <30 s
verzögert ≥30 s
Kategorie nach EN 954-1
unverzögert
verzögert <30 s
verzögert ≥30 s
Faults
• Earth fault
Supply voltage fails and the safety
contacts are opened via an electronic fuse.
Once the cause of the fault has been
removed and operating voltage is switched
off, the unit will be ready for operation after
approximately 1 minute.
• Contact failure: In the case of welded
contacts, no further activation is possible
following an opening of the input circuit.
• LED "POWER" is not illuminated if short-
circuit or the supply voltage is lost.
• Delay time aborted
In the case of an error, the delay-on de-
energisation contacts may open before the
delay time has elapsed.
Technical Data
Electrical data
Supply Voltage U
B
Voltage Tolerance
Power consumption at U
B
Frequency Range
Residual Ripple
Voltage and Current at
Input circuit
U
DC:
B
U
AC/DC:
B
Reset circuit
Feedback loop
Number of output contacts
Safety contacts (N/O)
instantaneous
delayed
Auxilliary contact N/C
Utilization category in accordance with
EN 60947-4-1
EN 60947-5-1(DC13: 6 cycles/min)
Contact material
External contact fuse protection
EN 60947-5-1 (I
= 1 kA)
K
Blow-out fuse quick
Blow-out fuse slow
Safety cut-out
Characteristic
Max. overall cable resistance R
lmax
input circuits
Single-channel DC
Single-channel AC
Dual-channel with detection of
shorts across contacts DC
Dual-channel with detection of
shorts across contacts AC
Dual-channel without detection of
shorts across contacts DC
Dual-channel without detection of
shorts across contacts AC
Safety-related characteristics of
the safety outputs
PL in accordance with
EN ISO 13849-1
instantaneous
delayed<30 s
delayed ≥30 s
Category in accordance with
EN 954-1
instantaneous
delayed<30 s
delayed ≥30 s
Erreurs - Défaillances
• Défaut de masse
• Défaut de fonctionnement des contacts de
• LED "POWER" éteinte: tension d'alimentation
• Temporisation interrompue
Caractéristiques techniques
Données électriques
Tension d'alimentation U
Plage de la tension d'alimentation
Consommation pour U
Fréquence
Ondulation résiduelle
Tension et courant du
Circuit d'entrée
U
DC:
B
U
AC/DC:
B
Circuit de réarmement
Boucle de retour
Nombre de contacts de sortie
Contacts de sécurité (F)
instantés
temporisés à retombée
Contact auxilliaire
Catégorie d'utilisation selon
EN 60947-4-1
EN 60947-5-1(DC13:
6 manoeuvres/min)
Matériau contact
Protection des contacts externe
EN 60947-5-1 (I
= 1 kA)
K
Fusibles rapide
Fusibles normal
Dijoncteur
Caractéristique
Résistance de câblage totale max.
lmax
R
circuits d'entrée
lmax
Commande par 1 canal DC
Commande par 1 canal AC
Commande par 2 canaux avec
détection des court-circuits DC
Commande par 2 canaux avec
détection des court-circuits AC
Commande par 2 canaux sans
détection des court-circuits DC
Commande par 2 canaux sans
détection des court-circuits AC
Caractéristiques techniques de
sécurité des sorties de sécurité
PL selon EN ISO 13849-1
instantés
temporisés à retombée <30 s
temporisés à retombée ≥30 s
Catégorie selon EN 954-1
instantés
temporisés à retombée <30 s
temporisés à retombée ≥30 s
- 6 -
La tension d'alimentation chute et les contacts
de sécurité sont ouverts par un fusible
électronique. Une fois la cause du défaut
éliminée et la tension d'alimentation coupée,
l'appareil est à nouveau prêt à fonctionner
après environ 1 minute.
sortie: en cas de soudage d'un contact lors de
l'ouverture du circuit d'entrée, un nouvel
réarmement est impossible.
non présente ou court-circuit interne.
En cas de défaut, les contacts temporisés à la
retombée peuvent s'ouvrir avant l'écoulement
de la temporisation.
AC/DC: 24 - 240 V
B
DC: 24 V
-15 ... +10 %
AC: 8,5 VA
B
DC: 5,0 W
AC: 50 - 60 Hz
DC: 160 %
24 V DC: 50 mA
24 V DC: 40 mA
24 V DC: 40 mA
24 V DC: 3,1 mA
3
2
1
AC1: 240 V/0,01 ... 8 A/
2000 VA
DC1: 24 V/0,01 ... 8 A/
200 W
AC15: 230 V/5 A;
DC13: 24 V/7 A
AgSnO
+ 0,2 µm Au
2
10 A
6 A
24 V AC/DC: 6 A
B/C
100 Ohm
150 Ohm
10 Ohm
20 Ohm
120 Ohm
200 Ohm
PL e (Cat. 4)
PL d (Cat. 3)
PL c (Cat. 1)
Cat. 4
Cat. 3
Cat. 1
