4. Assembly and operation

After you have checked the package contents as described in section 2, lay the parts out on
Master Reference
a clean, safe flat surface for the clearaudio assembly. Assembly is fairly
simple and straight forward as many parts have been preassembled at the factory. Please
use the white gloves provided to prevent scratches and/or fingerprints during assembly. The
Master Reference
smallest placing area for your clearaudio is 500 x 460 mm.
50 cm
46 cm
Place the premounted tri-star motor platform on any good turntable rack area optimised for
low sensitivity of acoustical feedback.
To prevent the surfaces of scratches, please use the included Flat Pads!
