Technical data

Rated output
Rated voltage
Fuse protection
Minimum conductor cross-section *
Warm water flow at rated output
with temperature increase from
12 °C to 38 °C
12 °C to 60 °C
Start-up flow
Start-up flow pressure **
Application area in water specific electric
resistance at 15 °C
Rated pressure
Maximum permissible supply temperature
Maximum mains impedance at connection point
Energy efficiency class
Load profile
Annual energy consumption
Daily energy consumption
Sound power level
Hot water heating energy efficiency
* Larger cable cross-sections may be required depending on the connection configuration.
** The pressure loss on the mixer must also be added.
Dimensions
E

Special accessories

Pipe kit DLE 02RBS: for use of the continuous-flow heater
as an under sink appliance
Priority switch (load shedding relay): for operation with
a priority circuit
Mounting kit DLE 02AP: for surface mount installation
10
EN
DEE 1803
[kW] 18
[V] 400
[A] 32
[mm 2 ] 4
[l/min] 9.9
[l/min] 5.4
[l/min] 2.6
[MPa (bar)] 0.025 (0.25)
[Ωcm] ≥ 1 300
[MPa (bar)] 1.0 (10.0)
[°C] 20
[Ω] ≤ 0.400
A
S
[kWh] 485
[kWh] 2.240
[dB] 15
[%] 38.0
DEE 2103 DEE 2403
21 24
400 400
32 40
4 6
11.6 13.6
6.3 7.2
2.6 2.6
0.025 (0.25) 0.025 (0.25)
≥ 1 300 ≥ 1 300
1.0 (10.0) 1.0 (10.0)
20 20
≤ 0.400 ≤ 0.400
A A
S S
485 485
2.241 2.240
15 15
38.0 38.0
