Control Keys (#4), Zoom Wheel (#5) and Power/Light Keys (#16)
One of the great features of WolfVision's portable Visualizers is that only the most necessary keys are on
the unit itself. Therefore anyone can use it without instructions:
#15
#14
#14 POWER key
Switches the unit on and off. When switching the unit on the Visualizer automatically runs power-on preset.
#15 LIGHT key
Switches the light of the Visualizer on and off. The LED beside the key indicates if the light is switched on.
The LIGHT key also works as ONE PUSH WHITE BALANCE key if pressed for 2 seconds (see page 8).
#16 SOURCE key /
Toggles between Visualizer image, external input and USB storage device (see page 9).
When the on-screen menu is activated, it works as navigation key (see page 11).
# 17 PRESET key / menu: navigation key - left
For storing the preset, press the PRESET key for more than 2 seconds. For recalling the preset, press the
PRESET key quickly (see page 7).
When on-screen menu is activated, it works as navigations key (see page 11).
#19 FREEZE key / menu: navigation key - up
Freezes the current image. The LED beside the key indicates the state (see page 7).
When the on-screen menu is activated, it works as navigation key (see page 11).
#19 ZOOM WHEEL
Turn the wheel down to zoom in (TELE), and up to zoom out (WIDE). The more you turn the ZOOM
WHEEL, the faster the zooming works.
#20 AUTO FOCUS (AF) key / menu: navigation key - right
Switches the auto focus on and off. The LED beside the key indicates the state (see page 7).
Press and hold for two seconds activates the manual focus mode, use the navigation keys up/down to
focus near/far.
When on-screen menu is activated, it works as navigations key (see page 11).
#21 MENU key / menu: OK key and HELP key
Activates the on-screen menu (see page 11).
When on-screen menu is activated, it works as OK key. Press and hold for two seconds opens the help
function.
menu: navigation key - down
#18
#17
#16
4
#19
#20
#21
