OWNER'S MANUAL

PARTS NAMES

INDOOR UNIT
Indoor unit
Air outlet
1
2 Operation panel
3
Horizontal air ow control louver
4 Vertical air ow control louver
Air inlet(2 sides)
5
All the pictures in this manual are for explanation purpose only. They may be slightly different from the air conditioner
you purchased(depend on model).The actual shape shall prevail.
10
5
6
NOTE
55
OUTDOOR UNIT
9
8
7
Outdoor unit
Drain pipe, vent pipe
6
Connection cable
7
Connection pipe
8
9 Refrigerant pipe port
Air outlet
10
