ACTIVE STAGE MONITOR

BLOCK DIAGRAM

COMBI INPUT
LINK

CONNECTOR PINOUT

© 2022 HH Electronics Ltd
LEVEL
PREAMP
FRONT OF HOUSE
Balanced XLR
(solder pin view shown)
GND
+
2
1
-
3
MALE
6.3mm stereo jack
GND
6.3mm mono jack
GND
Unbalanced signal cables can be used for
interconnects, but are more sensitive to noise pickup,
especially over long runs.
Designed and Engineered in the UK by HH Electronics LTD.
MODE
MONITOR
GND
+
1 GROUND
2 HOT
2 1
3 COLD
-
3
FEMALE
TIP HOT
RING COLD
SLEEVE GROUND
-
+
TIP
HOT
SLEEVE GROUND
+
LIVE SOUND
LOUDSPEAKERS
HIGH
FREQUENCY
AMP
PASSIVE
2 WAY
CROSSOVER
LO/MID
FREQUENCY
