HH Electronics TENSOR TRM-1201 Bedienungsanleitung Seite 5

ACTIVE STAGE MONITOR
INTRODUCTION
The HH Tensor TRM-1201 Engineered in the UK to deliver power, performance and reliability.
The Tensor TRM-1201 is a compact, active stage monitor; featuring a HH high-grade 12-inch driver with 1-inch compression driver.
The ultra efficient 1400 Watt Class D amplifier delivers optimal power output for demanding applications. Dual audio modes
provide effective voicing options for versatile operation, whether that's live band, DJ or conference.
The 6.3mm / XLR combination input socket enables simple connection. Combined with a painted, light-weight solid plywood
enclosure with 35mm pole mount for tripod mounting, the Tensor TRM-1201 is the perfect active monitoring solution.
GETTING STARTED
This manual contains important information regarding correct and safe operation of your Tensor system. Please read it thoroughly in order to
get the best performance and reliability from your HH product.
VOLTAGE SELECT SWITCH
Although every effort has been made to select the correct voltage for the region of use, please check before
powering up for the first time. Damage could occur if the voltage is incorrectly set. If necessary, use
a suitable tool to slide the Voltage Selector Switch to the required setting.
POWER CYCLE
Many products have large transient surges at turn on and off which can cause damage to your speakers.
Following the sequence below for power-up and the reverse for power down will prevent this from
occurring.
1
POWER
POWER SWITCH - OFF
4
INPUT 1
CONNECT INPUT SIGNAL
© 2022 HH Electronics Ltd
2
VOLUME
0
SET VOLUME TO MINIMUM
5
POWER
POWER SWITCH - ON
Designed and Engineered in the UK by HH Electronics LTD.
3
10
6
SET VOLUME AS REQUIRED
LIVE SOUND
100-120V setting
100-120V~ 220-240V~
VOLTAGE SELECT
220-240V setting
100-120V~ 220-240V~
VOLTAGE SELECT
CONNECT POWER
VOLUME
0 10
EN
5
