ACTIVE STAGE MONITOR
SPECIFICATIONS
Frequency Response
Crossover Frequency
Amplifier
Output Connector
AC Power Consumption
Enclosure
Unit dimensions (HWD)
Carton dimensions (HWD)
For polar plots, EASE modelling files, 2D and 3D drawings files, please check www.hhelectronics.com
1 Measured in Full space (4π) conditions.
2 Calculated maximum SPL based on rated power handling.
LEFT
© 2022 HH Electronics Ltd
Model TRM-1201
System Type 12" Active Powered Stage Monitor, Bass Reflex
1 50Hz - 20KHz (-10dB) (FOH mode)
55Hz - 18KHz (-3dB)
LF Driver 12-inch HH Driver
HF Driver 1 inch HH Compression Driver
2 130 dB SPL
Max SPL 1m
Coverage Angle 80° x 80°
2.8KHz
Power Rating 350W RMS, 700W Continuous, 1400W Peak
Limiter Dual Band Limiters
Input Connector Balanced Female XLR/6.3mm Jack Combi Socket
Balanced Male XLR with ground lift switch
Signal Indicators Power, Signal Present, Clip Indicator
Controls Volume, Monitor/FOH mode
AC Power 100V-120V~/220-240V~+ 50/60Hz User Switchable
300W
AC Power Inlet IEC C14 INLET
Acoustically optimised Plywood cabinet with integrated carry handles
Cabinet
Finish Painted Black
Monitor Angle 35°
Pole Mount 35mm Pole Mount Socket Included
Rear reinforced heavy gauge steel grille with acoustic foam
Grille
340 x 510 x 500mm, 13.4" x 20.1" x 19.7"
17.7Kg, 39 lbs
Unit weight
605 x 540 x 470mm, 23.8" x 21.3" x 18.5" , 0.154 M3
Packed weight 21Kg, 46.3 lbs
EAN13 5060109457582
Designed and Engineered in the UK by HH Electronics LTD.
In the interest of continued development, HH reserves the right to amend product specification without prior notification.
DIMENSIONS (in mm)
TOP
FRONT
EN
LIVE SOUND
TOP BAFFLE
RIGHT
