Adjust the lowest adjusting hex bolt to obtain the deepest depth
of cut, following the method of "Adjusting the depth of cut".
Adjust the two remaining adjusting hex bolts to obtain shal-
lower depths of cut. The differences in height of these adjust-
ing hex bolts are equal to the differences in depths of cut.
To adjust the adjusting hex bolts, turn the adjusting hex
bolts with a screwdriver or wrench. The stopper block is
also convenient for making three passes with progres-
sively deeper bit settings when cutting deep grooves.
Switch action
CAUTION:
Before plugging in the tool, always
check to see that the switch trigger actuates
properly and returns to the "OFF" position when
released.
CAUTION:
Make sure that the shaft lock is
released before the switch is turned on.
To prevent the switch trigger from being accidentally
pulled, a lock button is provided.
► Fig.4: 1. Lock button 2. Switch trigger
To start the tool, depress the lock button and pull the
switch trigger. Release the switch trigger to stop.
For continuous operation, pull the switch trigger and
then depress the lock button further.
To stop the tool, pull the switch trigger so that the lock but-
ton returns automatically. Then release the switch trigger.
After releasing the switch trigger, the lock-off function
works to prevent the switch trigger from being pulled.
CAUTION:
Hold the tool firmly when turning
off the tool, to overcome the reaction.
Electronic function
The tool is equipped with the electronic functions for
easy operation.
Indication lamp
► Fig.5: 1. Indication lamp
The indication lamp lights up green when the tool is
plugged. If the indication lamp does not light up, the mains
cord or the controller may be defective. The indication lamp
is lit but the tool does not start even if the tool is switched
on, the carbon brushes may be worn out, or the controller,
the motor or the ON/OFF switch may be defective.
Unintentional restart proof
The tool does not start with the switch trigger pulled
even when the tool is plugged.
At this time, the indication lamp blinks in red and shows
the unintentional restart proof device is on function.
To cancel the unintentional restart proof, release the
switch trigger.
Soft start feature
Soft-start feature minimizes start-up shock, and makes
the tool start smoothly.
Constant speed control
Possible to get fine finish, because the rotating speed is
kept constant even under the loaded condition.
Speed adjusting dial
WARNING:
Do not use the speed adjusting dial
during operation. The router bit can be touched by the opera-
tor because of reaction force. This may result in personal injury.
CAUTION:
If the tool is operated continuously
at low speeds for a long time, the motor will get
overloaded, resulting in tool malfunction.
CAUTION:
The speed adjusting dial can be turned
only as far as 5 and back to 1. Do not force it past 5 or
1, or the speed adjusting function may no longer work.
The tool speed can be changed by turning the speed
adjusting dial to a given number setting from 1 to 5.
► Fig.6: 1. Speed adjusting dial
Higher speed is obtained when the dial is turned in the
direction of number 5. And lower speed is obtained
when it is turned in the direction of number 1.
This allows the ideal speed to be selected for optimum
material processing, i.e. the speed can be correctly
adjusted to suit the material and bit diameter.
Refer to the table for the relationship between the num-
ber settings on the dial and the approximate tool speed.
Number
1
2
3
4
5
ASSEMBLY
CAUTION:
Always be sure that the tool is switched
off and unplugged before carrying out any work on the tool.
Installing or removing the router bit
CAUTION:
Install the router bit securely.
Always use only the wrench provided with the tool.
A loose or overtightened router bit can be dangerous.
NOTICE:
Do not tighten the collet nut without
inserting a router bit or install small shank bits
without using a collet sleeve. Either can lead to
breakage of the collet cone.
1. Insert the router bit all the way into the collet cone.
2. Press the shaft lock to keep the shaft stationary
and use the wrench to tighten the collet nut securely.
► Fig.7: 1. Collet nut 2. Tighten 3. Loosen 4. Wrench
5. Shaft lock
3.
When using router bits with other shank diameter, use the
correct size collet cone for the router bit which you intend to use.
► Fig.8: 1. Correct size collet cone
4. To remove the router bit, follow the installation
procedure in reverse.
9 ENGLISH
-1
min
8,000
12,000
16,000
20,000
27,500
