Endress+Hauser Promag 300 Installationsanleitung Seite 12

EA01164D
Fit the adhesive label (DKZ004):
Replace the adhesive label with the new terminal designation in the connection compartment.
Fit the nameplate:
Fit the nameplate (optional) according to the existing device labeling (see also Section 3
→  6 Authorized personnel).
Following modification, back up the data in the device memory or via Web server/
Fieldcare.
8.1.2 Entering the software license code: via Web server
Activate application packages:
Open the Web server:
1. Select the language
Log into the Web server:
2. Web server language: select the language
3. Login → Access authorization → Maintenance → Enter activation code: entry code factory
setting = 0000 or enter the entry code defined by the customer (
code). Ask the customer if you do not know the entry code. The new code can only be entered
in the "Maintenance" user role.
4. Menu! menu bar
5. Main menu
6. Expert
7. System
8. Administration
9. Activate the software option: enter the software license code (appl. package code), which
can be found on the wired-on tag plate supplied.
10. Click "OK" to confirm the software license code
11. Software option overview →: the activated software option(s) is/are displayed
Switch the I/O functionality, activate I/O hardware:
Open the Web server:
1. Select the language
Log into the Web server:
2. Web server language: select the language
3. Login → Access authorization → Maintenance → Enter activation code: entry code factory
setting = 0000 or enter the entry code defined by the customer (
code). Ask the customer if you do not know the entry code. The new code can only be entered
in the "Maintenance" user role.
4. Menu! menu bar
12
do not enter the service
do not enter the service
Endress+Hauser
