Teileliste; Spezifikation - Taurus 3D Smith Machine Montage- Und Bedienungsanleitung

7.2

Teileliste

Nr. Bezeichnung (ENG)
1 reinforcing plate
2 L shape base frame
3 hexagon bolt
4 washer
5 lock nut
6 slide rod
7 fix plate right
8 rubber cushion
9 connection tube
10 fix plate left
11 allen bolt
12 stand tube
13 out hexagon bolt
14 rubber pad
15 out hexagon bolt
16 guide rod
17 safety hook right
18 safety hook left
19 hexagon socket screw without head
20 barbell rod
21 sliding sleeve
22 barbell plate holder
23 washer
24 spring gasket
25 hexagon socket screw
26 chip up bar
27 out hexagon bolt
28 butterfly clip
29 L shape connect plate
30 simit column
31 simit nut

Spezifikation

M10*120
Φ10
M10
Φ60*Φ30*30
M10
M10*75
M10*70
M8
φ12
φ12
M12*40
M10*65
Anz.
2
2
8
38
18
2
1
4
4
1
4
2
8
4
2
2
1
1
4
1
2
2
2
2
2
1
2
2
2
28
28
27
