English
ACOUSTIC COVERAGE
OF SPEAKER WITH HORN
ROTATED

MECHANICAL FEATURES

The top and bottom of the speaker are equipped with attachment
fittings for the mounting brackets (optional). These attachment fittings
allow adjustment of the tilt angle with the speaker in the horizontal
position, and rapid fixing in the vertical position. See the ACCESSORIES
section.

PROTECTION AGAINST SOLID OBJECTS AND LIQUIDS (IP RATING)

The speaker is protected against the ingress of solid objects and liquids with a rating of IP32 as defined by
EN 60529.
To guarantee this specification is met, the speaker must be installed horizontally or vertically facing downwards
with a tilt angle of at least 15° to the vertical.
The cable connecting the speaker to the amplifier must have a diameter of at least 8mm (0.31 inch).
Failure to comply with these installation prescriptions could adversely affect the declared
protection ratings.
IS25T
VISTA LATERALE PER FIX STAFFE
Cod. 420120376 REV. 1.0
15
