Specifications

1. Type: smartLAB
2. Measuring range: 20 ~ 630 mg/dL
(1.1 ~ 35.0 mmol/L)
3. Measuring duration: 5 seconds
4. Time mode: AM/PM - 24 hours
5. Memory: 480 values
6. Operating temperature: 10°C ~ 40°C
(50°F ~ 104°F)
7. Storage Temperature: -20°C ~50°C
(-4°F~122°F)
8. Relative humidity: RH ≤90%
Front
Display-
Shows results,
messages, and
results stored in
memory.
Left Button-
Press to enter
memory, adjust
setting, and
scroll through results.
Side
® sprint nG
Test Strip Slot-
Insert test strip
here.
Strip Ejector-
Push the Strip
Ejector to
remove the strip.
9. Blood sample: ≥ 0,6 µL capillary
fresh blood or venous whole blood from
fingertips, palm, or forearm
10. Calibration: Plasma equivalent
11. Hematocrit (Hct): 30-55%
12. Battery type: 2 1,5 V AAA Lithium
batteries
13. Battery life: over 2000
measurements
14. Display-size: 43 x 35 mm
15. Meter dimensions: 98 x 57 x 22 mm
13. Weight: 53,2 g (without batteries)
Back
Battery Door-
Flip open the battery
door by pushing the tab
in the direction of the
arrow and pulling the
door up.
Right Button-
Press to turn the meter
on, confirm
setting, and scroll
through results.
53
