5.5.6 Slot/Index-Tabellen
Gerätemanagement
Parameter E+H Matrix
(CW II)
Directory object
header
Composite list
directory entries
Analog-Input-Block
Parameter E+H Matrix
(CW II)
Standardparameter
Block Data
Static revision
Device tag
Strategy
Alert key
Target Mode
Mode
Alarm summary
Batch
Gap
Blockparameter
Out V6H2 (Wert)
V6H3 (Status)
PV Scale
Out Scale
Linearisation type
Channel
Gap
PV fail safe time
Fail safe type
Fail safe value
Alarm Hysteresis
Gap
HI HI Limit
Gap
HI Limit
Gap
LO Limit
Gap
Levelflex M FMP45 mit PROFIBUS PA
Slot Index Size Type
[bytes]
1 0 12 Array of
UNSIGNED16
1 1 24 Array of
UNSIGNED16
Slot Index Size Type
[bytes]
1 16 20 DS-32*
1 17 2 UNSIGNED16
1 18 32 OSTRING
1 19 2 UNSIGNED16
1 20 1 UNSIGNED8
1 21 1 UNSIGNED8
1 22 3 DS-37*
1 23 8 DS-42*
1 24 10 DS-67*
1 25
1 26 5 DS-33*
1 27 8 Array of FLOAT
1 28 11 DS-36*
1 29 1 UNSIGNED8
1 30 2 UNSIGNED16
1 31
1 32 4 FLOAT
1 33 1 UNSIGNED8
1 34 4 FLOAT
1 35 4 FLOAT
1 36
1 37 4 FLOAT
1 38
1 39 4 FLOAT
1 40
1 41 4 FLOAT
1 42
Read Write Storage
Class
X constant
X constant
Read Write Storage
Class
X constant
X non-vol.
X X static
X X static
X X static
X X static
X dynamic
non-vol.
constant
X dynamic
X X static
X dynamic
X X static
X X static
X X static
X X static
X X non-vol.
X X static
X X static
X X static
X X static
X X static
X X static
