INTERCONNECTION
BEFORE CONNECTING
For the professional installation of a sound system, car audio
retail stores offers appropriate wiring kits. Ensure a sufficient
profile section (refer to the table below) and a suitable fuse rat-
ing and the conductivity of the cables when you purchase your
wiring kit. Clean and remove rust-streaked and oxidized areas
on the contact points of the battery and the ground connection.
Make sure that all screws are fixed tight after the installation,
because loose connections cause malfunctions, insufficient
power supply or interferences.
FUSE
1
The inserted fuses (2 x 40 A) are protecting the amplifier from shorts and capacity overload. If you
need to replace the fuse, make sure to use the same type of fuse with the same rating.
POWER
2
Connect the POWER + terminal with the +12V pole of the vehicle's battery. Use a suitable cable with
a sufficient cross section (refer to the table below).
Connect the POWER – terminal with a suitable contact ground point on the vehicle's chassis. The
ground wire must be as short as possible and must be connected to a blank metallic point at the
vehicle's chassis. Ensure that this ground point has a stable and safe electric connection to the nega-
tive "–"pole of the battery. Check this ground wire from the battery to the ground point if possible and
enforce it if required. Use a ground wire with a sufficient cross section (refer to the table below) and
the same size like the +12V power supply wire.
ADDITIONAL CABLE FUSE (NOT INCLUDED)
Install an extra fuse (not included) for the +12V power cable near the battery to secure the power
cable. The distance between the fuse and the battery should not exceed 30 cm. The fuse size must be
adapted to the cable cross-section of the installed power cable (see table below).
IMPORTANT: The fuse on the battery does not protect the amplifier, but the cable between the battery
and the amplifier against short circuits.
Fuse Value
0 - 1,2
20 - 35 A
35 - 50 A
50 - 65 A
65 - 85 A
85 - 105 A
105 - 125 A
Recommended minimum cable cross-section to guarantee full amplifier performance:
Up to a length of 3 m: 20 mm
From a length of 3 m: 25 mm
Replace defective fuses only with a new one of the same type and with the same fuse rating.
1,2 - 2,1
2,1 - 3,1
4
6
10
6
10
10
10
10
16
16
16
20
16
16
20
20
20
20
/ Full OFC cable
2
/ Full OFC cable
2
Cable length in meters
3,1 - 4,0
4,0 - 4,9
10
16
16
16
20
20
20
35
35
35
35
35
Minimum cable cross-section in mm
ENGLISH
1
2
4,9 - 5,8
5,8 - 6,7
6,7 - 8,5
16
16
20
20
20
20
35
35
35
35
50
50
2
20
20
35
50
50
50
7
