Cleaning And Care; Maintenance; Disposal; Return Old Equipment - Seto ALDEBARAN 360 GRAD FLEX-C 2.0 Gebrauchsanleitung

For cleaning the plastic / metal parts, do not use any solvents, alcohols or other chemicals. For removing dirt,
dust, oil, grease etc., use a soft, dry and lint-free cloth.
WARNING! Electrical current!
Before every cleaning, the device must generally be disconnected from the supply grid by pulling out the grid
plug.
Die Leuchte ALDEBARAN
maintenance work is necessary. The product is repairable. Individual components can be replaced or repaired by a
specialist if necessary.
WARNING! Electrical current!
Before every maintenance, the device must generally be disconnected from the supply grid by pulling out the
grid plug.
At the end of its useful life, this product must not be disposed of together with normal household waste,
but has to be dropped off at a collection centre for the recycling of electrical and electronic devices. This
is indicated by the symbol on the product, on the instruction manual or on the packaging.
The materials of which this product is made are recyclable pursuant to their labelling. With the reuse,
the recycling of the materials or other forms of scrap usage you are making an important contribution to the
protection of the environment. Please ask your local administration office for the appropriate disposal centre.
We take care of eco-friendly disposal of your old equipment, refer directly to your SETOLITE team!
Type
Input voltage
Frequency
Active cooling
Power consumption approx.
Illuminant
Permissible operation temperature
IP code
Class of protection
Dimensions (Ø x H)
Weight approx.

Cleaning and care

Maintenance

360 GRAD FLEX-C 2.0 luminaire was designed to be maintenance-free. Therefore, no
®

Disposal

Return old equipment

Technical data

ALDEBARAN 360 GRAD
®
FLEX 960 2.0
Yes
960 W
4 x LED module à 240 W
IP54
235 x 812 mm
21 kg
ALDEBARAN 360 GRAD
®
FLEX 360 IP65 2.0
110-240 V AC
50 / 60 Hz
No
500 W
4 x LED module à 125 W 4 x LED module à 150 W
-30 to +40 °C
IP65
I
235 x 812 mm
18 kg
ALDEBARAN 360 GRAD
®
FLEX 600 COMPACT 2.0
Yes
600 W
IP54
235 x 537 mm
15 kg
15
