Preparation for operation

Connectors (only -C versions):
To connect the supply lead, insert the cable connector
of the lead into the cable socket of the luminaire
and turn it clockwise. To disconnect the lead, turn the
connector counterclockwise and pull out the cable
connector.
WARNING! Electrical current!
Make sure that the luminaire is disconnected from the
mains supply before connecting or disconnecting the
supply line.
Error
One light module without function
Two light modules without function
All four light modules without function
Luminaire cannot be dimmed
Extreme discrepancy in the brightness
of one light module
14
Cable plug
(illuminant)
Cable connector
(supply line)

Malfunction

Possible cause
Defect in light module
Switch OFF
No voltage
Defect of the rotary knob
Defect of the active cooling
ATTENTION!
Luminaire may only be operated with the original
supply cable, supply line in replacement / repair
only from manufacturer or his service representative.

Control unit

The ALDEBARAN 360 GRAD FLEX-C 2.0 luminaire can
®
be controlled via the two switches and the rotary knob
(only with dimmable versions) on the control unit. The
control unit is integrated into the supply line.
With every switch, two light modules are switched
(ON / OFF).
By turning the potentiometer clockwise, the illuminance
level can be increased, counter clockwise lowers the
illuminance level (only with dimmable versions).
Control unit
Solution
Ask your trained electrician or the
manufacturer
Check the control elements (switches)
Check the voltage supply
Ask your trained electrician or the
manufacturer
Ask your trained electrician or the
manufacturer
Potentiometer
Switch ON / OFF
