22
Infrared: Allow the user to choose how many LEDs
(On/One LED/Off)
will be turned on.
On: Every LEDs work when taking photos
or videos at night.
One LED: Only a single LED works (see
figure). This option can be useful when using
an IR-Booster/Black LEDs IR-Booster (sold
separately, refer to the section "OPTIONS").
Off: LEDs are deactivated so your night
photos or videos are pitched black.
Side Sensors:
When the side sensors are activated, a total of
(On/Off)
7 zones is covered. The central sensor covers
5 zones. The side detectors are mainly used
to prepare the camera so when your target
passes through the central sensor, the system
is already pre triggered, increasing greatly
the reaction time of your camera.
Note: The side sensors require more battery
power.
LED for
infrared
sensor
TINY-W 2
s: side sensors
c: central sensor
Viewing angle
30°
Camera
Detection angles
Time Lapse: Allow the user to set the frequency at which
(Off/30s/1m/3m/
time the camera takes a picture, without
5m/15m/30m/1h)
detection.
"5 minutes" is selected in the "Time Lapse"
mode, the camera takes a picture every 5
minutes during that period of operation (time
start and time stop) even if there is no detection.
This option allows the user to obtain
pictures of game outside the detection range
of the camera.
Note: The "Time Lapse" mode only applies
in "PHOTO" mode, not in "VIDEO" mode.
When "Time Lapse" mode is selected, the
"Delay" mode and the "Multi-shot" mode
are disabled. In addition, the photo
resolution is reduced to 800 x 600 to allow
the possibility of video editing.
26'
40° 70°
(8m)
50' Detection distance
(central)
(15m)
30' Detection distance
of the side sensors
(9m)
For example, if the option
23
