EN
STEP 3.
Connect the heart rate cables (45) to the
connecting cables (42) and the computer cable
(30) to the computer connecting cable (43).
Use hexagonal bolts (14), spring washers (13),
and curved washers (12) to screw the
handlebar post (5) on to the main frame (1).
STEP 4.
Fix the handlebar grip (56) to the handlebar
post (5) with the handlebar angle adjustment
handle (53), handlebar cover (54), separator
(55), and flat washer (15) as shown in the
picture.
Connect the heart rate cables (45) and the
computer cable (30) protruding from
the handlebar post (5) to relevant computer
cables (44). Fix the computer (44)
to the handlebar post (5) using cross-head
screws (59).
STEP 5.
Slide the seat guide (4) into the seat frame (2).
Then, screw the guide (4) to the main frame (1)
using hexagonal bolts (14), spring washers (13)
and washers (15).
Install the water bottle holder (23) on the
handlebar post (5) using screws (24) and flat
washers (29). Make sure the holder is secure
and insert the bottle (60).
