TCX07, TCX14, TCX21, TCX35
TCX14, TCX21, TCX35
➤ To switch between cooling mode and heating mode, press the
HOT/COLD button (fig. 4 4, page 4).
I
NOTE
The control unit of the cooling box has a memory function. It memorizes
the selected temperature range for each mode (cooling and heating).
Thus the temperature range which was previously selected in the
respective mode is set again with each switching on or switching over.
✔ The blue operating display (fig. 4 3, page 4) or the red operating display
(fig. 4 2, page 4) lights up and the cooling box starts cooling or heating.
6.10 Selecting the temperature (TCX14, TCX21, TCX35)
The temperature status display (fig. 4 5, page 4) indicates the selected
temperature. With an increasing number of illuminated LEDs, the cooling or heating
intensity also increases.
I
NOTE
The following temperature indications are subject to tolerances and are
dependent on the measuring position.
Temperature at interior center at approx. 25 °C ambient temperature:
Temperature status display
(fig. 4 5, page 4)
7 illuminated LEDs
Cooling
1 illuminated LED
7 illuminated LEDs
Heating
1 illuminated LED
➤ To select the temperature, press the button (fig. 4 6, page 4) repeatedly until
the desired number of LEDs lights up.
EN
Interior temperature
approx 1 °C (TCX14)
approx 3 °C (TCX21, TCX35)
approx 17 °C (ECO mode)
approx 65 °C
approx 48 °C
Operation
19
