NEO TOOLS 90-062 Originalanleitung Seite 7

the heating element works at half power
the heating element is working at full power)
4.2 Right Knob : Thermostat dial
5. Special safety regulations
5.1 Before use, please check the marking on the power cord. Depending on the power cord type this appliance may be used in different ambient
conditions:
Type
H07RN-F
H05RN-F
H05RR-F
5.2 When using electrical appliance basic precautions should always be followed including below :
5.2.1 The fan heater is not suitable for use outdoors in damp weather, in bathrooms or in other wet or damp environments.
5.2.2 Please note that the fan heater can become very hot and should, therefore, be placed at a safe distance from flammable objects such as
furniture, curtains and similar.
5.2.3 Do not cover the fan heater.
5.2.4 The fan heater must not be located immediately below a socket outlet.
5.2.5 Do not connect the fan heater using an on/off timer or other equipment which can automatically switch the device on.
5.2.6 The fan heater must not be placed in rooms where flammable liquids or gases are used or stored.
5.2.7 If an extension cord is used, it must be as short as possible and always be fully extended.
5.2.8 You must not connect other appliances to the same mains socket as the fan heater.
5.2.9 Do not use this fan heater in the immediate surroundings of a bath, a shower or a swimming pool
5.2.10 If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
5.2.11 Make sure heater is always under surveillance and keep children and animals away from it;
5.2.12 Do not place the appliance on moving vehicles or some where easy to be tipped over .
5.2.13 When you don't use the appliance for a long time, unplug the appliance .Don't leave the heater for a considerable amount of time when in use.
Pull the plug straight out ,never remove the plug by pulling on the cord .
5.2.14 Keep the heater far from curtain or places where the air inlet can easily be blocked.
5.2.15 The power coupler is waterproof when not in sue. In order to prevent possible electric shock or leakage current ,never use the appliance with
wet hand or operate the appliance when there is water on the power cord.
5.2.16 Do not dispose of electrical appliances as unsorted municipal waste,use separate collection facilities. Contact you local government for
information regarding the collection systems available.If electrical appliance are disposed of in landfills or dumps, hazardous substances can leak
into the groundwater and get into the food chain,damaging your health and well-being.
5.2.17 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their
safety.
5.2.18 Children should be supervised to ensure that they do not play with the appliance.
6. Using Instructions
6.1 Position the fan heater so that it stands upright on a firm surface and at a safe distance from wet environments and flammable objects.
6.2 Connect the fan heater to the mains.
6.3 Set the thermostat knob to the MAX and let the heater operate with full power.
6.4 The fan heater will switch on when the heating selector is set to one of the power settings.
6.5 Once the room reaches the required temperature, heating element will stop working but fan also working .Once the temperature decreased, the
heating element will be working. The fan heater now starts and stops automatically and thus keeps the room temperature constant.
6.6 Before switch off the heater, please turn the thermostat to MIN position and turn the switch to fan position, let the appliance cool down for two
minutes then turn off the heater and pull out the plug.
7. Cleaning and Maintenance
7.1 Before cleaning the appliance,disconnect it from the socket and let it cool down. The enclosure is easily to get dirty, wipe it often with soft sponge.
For every dirty parts, wipe with a sponge dipped in <50°C water and mild detergent,then dry the heater enclosure with clean cloth. Be careful not to
let the water enter the appliance inner. Don't splash water onto the heater,never use solvent like gasoline etc. to clean the heater,in order to protect
the enclosure.
7.2 Clean the cord and plug,dry and pack it in a plastic bag.
7.3 When you store the heater, let it cool down first, keep it dry. Then cover it with a plastic bag, put in a packing box and store it in a dry, ventilated
place.
8. Trouble shooting:
You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the
problem before calling the service centre.
Problem
The heater does
operate,even when it is plugged
in and the switch, thermostat are
switched on .
The heating element glowing
You can use the appliance in
household, warehouses and workshops, building sites or greenhouses
household, warehouses and workshops or greenhouses
household, warehouses and workshops
Possible cause
not
The plug is loose, bad connection
No power in socket outlet
The input voltage is too high or too low
The air inlet grill is blocked
The switch was not put at heating setting
Do not use in
building sites
building sites or greenhouses
Treatment
Pull out the plug, check the connection of the plug and
socket. Then connect again.
Insert the plug in a proper socket
Use power supply according to the rating on the label
Keep the heater far way from articles like curtain, plastic
bag, paper and other things which can cover the inlet or
can be easily cover on the air inlet
Turn the switch to heat setting
