Podsumowanie:
W przypadku miejscowych elektrycznych ogrzewaczy pomieszczeń zmierzona sezonowa efektywność energetyczna ogrzewania pomieszczeń
ηs nie może być gorsza niż wartość deklarowana nominalnej mocy cieplnej urządzenia.
EN
NOTE: BEFORE THE EQUIPMENT IS USED FOR THE FIRST TIME, READ THIS INSTRUCTION MANUAL AND KEEP IT FOR FUTURE
REFERENCE. PEOPLE WHO HAVE NOT READ THIS INSTRUCTION SHOULD NOT ASSEMBLE, LIGHT, ADJUST OR OPERATE THE UNIT
DETAILED SAFETY REGULATIONS
ATTENTION!
Read carefully-The infrared heater is designed for safe operation. Nevertheless, installation, maintenance and operation of the heater can be
dangerous. Observing the following procedures will reduce the risk of fire, electric shock, injury to person and keep installation time to a minimums.
1.1 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
1.2
WARNING: In order to avoid overheating, do not cover the heater.
1.3 Children of less than 3 years should be kept away unless continuously supervised.
1.4 Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended
normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved.Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.
1.5 CAUTION-some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable
people are present.
2. Introduction
2.1 Depending on the power cord type his fan heater may be used only in household, warehouses and workshops, building sites or greenhouses
depending. It incorporates a thermostat and a self-resetting thermal cut-out to control the heating elements. The thermostat feels the air temperature
and controls the surrounding temperature. The fan motor is controlled by thermostat and it stops when the thermostat cuts off the heating element.
The self-resetting thermal cut-out will switch off the heater to ensure the safety when overheating.
3. Technical specifications
Model
Voltage
required power
current
Required Fuse
Setting
Self-resetting Thermostat
Size of heater ( mm)
N.W.( KG)
3.1 Housing of steel plate and coated by heat-resistant powder .
3.2 Supplied complete with cord and plug .
4. Description of Control Panel
90-062
4.1 Left Knob : selector with heat setting
the device is turned off
fan on
Grupa Topex Sp. z o. o. Sp. k. Ul. Pograniczna 2/4, 02-285 Warszawa
TRANSLATION OF THE ORIGINAL INSTRUCTION
90-062 / 90-063 / 90-064
90-062
220-240V
2000W
8.3-9.1A
10A
25/1000/2000W
65°C
210*160*217
1.7
90-063
Regulacja temperatury w
pomieszczeniu z wykrywaniem
otwartego okna
Z regulacją na odległość
Z adaptacyjną regulacją startu
Z ograniczeniem czasu pracy
Z czujnikiem ciepła promieniowania
90-063
90-064
220-240V
380-400V 3~
3000W
5000W
12.5A-13.6A
7.2-7.6A
16A
10A
25/1500/3000W
50/3300/5000 W
85°C
75°C
265*210*290
300x235x345
2.85
4.32
90-064
[nie]
[nie]
[nie]
[nie]
[nie]
