Installation and set-up / operation
Level at power on
Reset
Technical information / Functioning / Parameters
Adjustable parameters
Switch-on point: Upper limit value at which the output changes its switching status.
• indicated in cm or inch
setting range
LK3022
LK3023
LK3024
Switch-off point: Lower limit value at which the output changes its switching status.
• indicated in cm or inch
setting range
LK3022
LK3023
LK3024
Dependence between rP1 and SP1:
1. rP1 is always lower than SP1. The unit only accepts values which are lower than SP1.
2. If the difference between rP1 and SP1 is small (approx. 3 x steps), increasing the switch-on
point also increases the switch-off point (the difference SP1 - rP1 remains constant).
3. If the difference between rP1 and SP1 is great, rP1 remains at the set value even if SP1 is
increased.
4. If SP1 is set to the minimum value and then increased, rP1 is also set to the minimum
value and increased proportionally.
Page 24
All manuals and user guides at all-guides.com
At every power on the sensor initialises again. During this phase
ensure that the vessel is not completely filled.
Max. level at power on
in cm from the lower edge of the sensor
If a mounting element (flange, etc.) is in the active zone, the level must
have a minimum distance to the lower edge of the mounting element
at power on:
Minimum distance between the medium and
mounting element in the active zone [cm]
The values are maintained if you follow the mounting recommenda-
→ page 21).
tion
Always carry out a reset in the following cases (disconnect the sensor
briefly and then connect it again) so that the sensor initialises again.
Observe the indications in the two tables above.
• If the sensor has been removed from the vessel and then inserted
again during operation.
• If the active zone of the sensor has been touched with the hand or
grounded objects (e.g. a screwdriver).
• After a change of media if the dielectric constants differ much (e.g.
oil/water).
Programming menu
cm
2.5 ... 20.5
4.0 ... 41.5
6.0 ... 61.0
Values for OFS = 0; with OFS > 0 the OFS value is added to these values.
cm
2.0 ... 20.0
3.5 ... 41.0
5.0 ... 60.0
Values for OFS = 0; with OFS > 0 the OFS value is added to these values.
LK3022
LK3022
page 3
inch
1.0 ... 8.0
1.4 ... 16.2
2.5 ... 24.0
inch
0.8 ... 7.8
1.2 ... 16.0
2.0 ... 23.5
LK3023
LK3024
20
40.5
59.5
LK3023
LK3024
3
5
8
in steps of
0.5cm / 0.2inch
0.5cm / 0.2inch
1.0cm / 0.5inch
in steps of
0.5cm / 0.2inch
0.5cm / 0.2inch
1.0cm / 0.5inch
