Zimmer Biomet Zfx EIGER Gebrauchsanweisung Seite 4

Instruction Manual
Zfx Hex / Hexalobular
TM
Screwdriver
Refer to the below table for maximum torque recommendations for the
use of Zfx™ Hex / Hexalobular Screwdrivers.
Table 1
Item Name
GenTek™ Hexalobular Screwdriver, 21 mm
GenTek™ Hexalobular Screwdriver, 28 mm
GenTek™ Hexalobular Screwdriver, 36 mm
Zfx™ Hexalobular Screwdriver EIGER, 21 mm
Zfx™ Hexalobular Screwdriver EIGER, 28 mm
Zfx™ Hexalobular Screwdriver EIGER, 36 mm
Zfx™ Hexalobular Screwdriver JORASSES, 21 mm
Zfx™ Hexalobular Screwdriver JORASSES, 28 mm
Zfx™ Hexalobular Screwdriver JORASSES, 36 mm
Zfx™ Hexalobular Screwdriver MERU, 21 mm
Zfx™ Hexalobular Screwdriver MERU, 28 mm
Zfx™ Hexalobular Screwdriver MERU, 36 mm
Zfx™ Hex Screwdriver AORAKI, 21 mm
Zfx™ Hex Screwdriver AORAKI, 28 mm
Zfx™ Hex Screwdriver AORAKI, 36 mm
Zfx™ Hex Screwdriver BADILE, 21 mm
Zfx™ Hex Screwdriver BADILE, 28 mm
Zfx™ Hex Screwdriver BADILE, 36 mm
Zfx™ Hex Screwdriver DENALI, 21 mm
Zfx™ Hex Screwdriver DENALI, 28 mm
Zfx™ Hex Screwdriver DENALI, 36 mm
Zfx™ Hex Screwdriver FUJI, 21 mm
Zfx™ Hex Screwdriver FUJI, 28 mm
Zfx™ Hex Screwdriver FUJI, 36 mm
Zfx™ Hex Screwdriver PISCO, 21 mm
Zfx™ Hex Screwdriver PISCO, 28 mm
Zfx™ Hex Screwdriver PISCO, 36 mm
Zfx™ Hex Screwdriver VINSON, 21 mm
Zfx™ Hex Screwdriver VINSON, 28 mm
Zfx™ Hex Screwdriver VINSON, 36 mm
Zfx™ Hex Screwdriver EVEREST, 28 mm
