Specifications
Electrical
Voltage: 220V~240V 50Hz
Watts: 1300~1600 Watts
Amps: 6-6.7 A
Wiring: Plug-In
Bulb Type: LED
Dimensions
Winslow 36"
Width: 91.5 cm
Height: 44.1 cm
Height with feet: 51.0 cm
Depth: 12.8 cm
Depth with feet: 27.6 cm
Weight: 11.75 kg
Winslow 42"
Width: 106.7 cm
Height: 46.0 cm
Height with feet: 52.9 cm
Depth: 12.8 cm
Depth with feet: 27.6 cm
Weight 15.3 kg
Winslow 48"
Width: 121.9 cm
Height: 46.0 cm
Height with feet: 52.9 cm
Depth: 12.8 cm
Depth with feet: 27.6 cm
Weight: 16.5 kg
- 16 -
Installation
GROUNDING INSTRUCTIONS
• This product is equipped with a cord that has
an equipment-grounding conductor and a
grounding plug. The plug must be plugged into
an appropriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances.
• This heater is for use on 220-240 volts.
• A 10 Amp, 220-240 Volt circuit is required.
A dedicated circuit is prefer red, but not essential
in all cases. A dedicated circuit will be required if,
after installation, the circuit breaker trips or the
fuse blows on a regular basis when the heater is operating. Additional appliances on
the same circuit may exceed the current rating of the circuit breaker.
WARNING: Electrical outlet wiring must comply with local building codes and other
applicable regulations to reduce the risk of fire, electric shock, or injury to persons.
