GENERAL INFORMATION
RANGE
MODEL
TOP MODULANTE
Dear heating engineer,
We would like to congratulate you on having recommended a
solar station unit: a modern product that's capable of ensuring
a high degree of reliability, efficiency, quality and safety.
While your technical skills and knowledge will certainly be more
than sufficient, this booklet contains all the information that
we have deemed necessary for the device's correct and easy in-
stallation.
Thank you again, and keep up the good work,
9
For warranty conditions refer to what indicated in the prod-
uct in combination with the accessory.
CONTENTS
1
General Safety Information . . . . . . . . . . . . . . . . . . . . . 12
2
Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3
Description of the appliance . . . . . . . . . . . . . . . . . . . . 13
4
Safety and control devices. . . . . . . . . . . . . . . . . . . . . . 13
5
Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6
System layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7
Technical specifications. . . . . . . . . . . . . . . . . . . . . . . . 15
8
Unpacking the product . . . . . . . . . . . . . . . . . . . . . . . . 16
9
Installation premises . . . . . . . . . . . . . . . . . . . . . . . . . 16
10
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
11
Water connections . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
12
Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . 18
13
System flushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
14
System filling cock. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
15
Device cleaning and maintenance . . . . . . . . . . . . . . . 21
16
Interventions on the hydraulic system . . . . . . . . . . . . 21
17
Recycling and disposal . . . . . . . . . . . . . . . . . . . . . . . . 21
ENGLISH
The following symbols are used in this manual:
9
CAUTION! = Identifies actions that require caution and
adequate preparation.
0
STOP! = Identifies actions that you MUST NOT do.
1
GENERAL SAFETY INFORMATION
CODE
9
Check that the product is complete, undamaged and as or-
20156553
dered as soon as you receive it. Report any discrepancies or
damage to the dealer who sold it.
9
The product must be used for its intended purpose (as de-
scribed by the manufacturer) for which it has been expressly
manufactured. The manufacturer shall bear no responsibil-
ity, whether of a contractual or non-contractual nature, for
any damage caused to people, animals, or property due to
incorrect installation, adjustments, or maintenance, or im-
proper use.
9
The product must be serviced at least once a year. Servicing
must be arranged in advance with the Technical Assistance
Centre.
9
All servicing and repairs must be performed by a qualified
heating engineer.
9
This manual is an integral part of the appliance and must
therefore be taken good care of and must ALWAYS accom-
pany the appliance, even when it is passed on to another
owner or user or transferred to another system. if it gets
damaged or lost request another copy. Keep the product
purchase documents to be presented to the
Technical Assistance Centre to request a service call under
warranty.
9
Size the solar expansion tank so as to ensure complete ab-
sorption of the expansion of the fluid contained within the
system, with reference to the prevailing regulations on the
matter. In particular, consider fluid characteristics, consid-
erable fluctuation of service temperature and vapour that
might be generated during solar collector stagnation stage.
Proper size of expansion tank ensures setting off of all vol-
ume changes of the heat transfer fluid, avoiding excessive
pressure increase. Limited pressure changes avoid reach-
ing safety valve opening pressure and the consequent fluid
drainage.
General information
comprises
- Rev.
This manual, Code
pages.
12 12
At the end of its life, the product should be
not be disposed of as solid urban waste,
but rather it should be handed over to a
differentiated waste collection centre.
authorised
