DMX-protocol

3-Channel Mode (default setting)
Control-channel 1 – Dimmer
Value
000 - 255 Gradual adjustment of the dimmer intensity from 0 to 100 %
Control-channel 2 – Strobe
Value
000 - 000 No function
001 - 255 Strobe-effect with increasing speed
Control-channel 3 - Dimmer curves
Value
000 - 015 Control Board setting dimmer curve
016 - 045 Linear dimmer curve, response characteristics of halogen lamp
046 - 075 Square dimmer curve, response characteristics of halogen lamp
076 - 105 Inverse square dimmer curve, response characteristics of halogen lamp
106 - 135 S-shaped dimmer curve, response characteristics of halogen lamp
136 - 165 Linear dimmer curve, response characteristics of LED
166 - 195 Square dimmer curve, response characteristics of LED
196 - 225 Inverse square dimmer curve, response characteristics of LED
226 - 255 S-shaped dimmer curve, response characteristics of LED
1-Channel Mode
Control-channel 1 – Dimmer
Value
000 - 255 Gradual adjustment of the dimmer intensity from 0 to 100 %
Characteristic
Characteristic
Characteristic
Characteristic
28/32 00133815, Version 1.0
