DESCRIPTION OF THE DEVICE
5
6
7
(10) Carrying handle
(11) Rubber foot
(12) 5-pin DMX input
(13) 3-pin DMX input
(14) USB port for QuickDMX receiver
(15) Power input
(16) Fuse holder
(17) Power output
(18) Manual zoom
(19) 5-pin DMX output
(20) 3-pin DMX output
21
22
23
24
25
26
1
2
(1) Mounting hole for the coupler
3
(2) Mounting bracket
4
(3) Mounting hole for the safety bond
(4) Venting slots
(5) Housing
(6) Fresnel lens
8
(7) Barn doors
9
(8) Fixation lever
(9) Holder for the color filter frame
and barn doors
10
11
(21)
(22)
(23)
(24)
(25)
(26)
22/32
12
13
14
15
16
17
18
19
20
Enter button
Mode button
LCD
Up button
Down button
Manual brightness rotary dial/
dimmer control
00133815, Version 1.0
