Note:
o The safety distance between the hotplate and the cupboard above the hotplate
should be at least 760 mm.
A (mm) B (mm)
760 50 min.
WARNING! Ensuring adequate ventilation:
o Make sure the hob is well ventilated and that the air inlet and outlet are not blocked.
In order to avoid accidental contact with the excess heat at the bottom of the hob,
or getting an unexpected electric shock when working, it is necessary to place a
wooden insert, fixed by screws, at a minimum distance of 50 mm from the bottom of
the hob. Follow the specifications below.
o There are ventilation holes around the outside of the hob. You MUST ensure these
holes are not blocked by the worktop when you put the hob into position.
o Be aware that the glue that joins the plastic or wooden material to the appliance has
to resist temperatures up to 150℃ to avoid the panelling becoming unstuck.
o The rear wall, adjacent and surrounding surfaces must therefore be able to withstand
temperatures of 90℃.
Gebrauchsanweisung ○ Mode d'emploi ○ Istruzioni per l'uso ○ Instruction for use
C (mm) D
20 min. Air intake
112
E
Air exit 5 mm
