RF RxT SW2.4 4W(-VAL) 24 VAC/DC
//
Montage- und Anschlussanleitung / Funk-Empfänger
Mounting and wiring instructions / Wireless receiver
Instructions de montage et de câblage / Récepteur radio
Istruzioni di montaggio e collegamento / Ricevitore wireless
Instruções de montagem e instalação / Receptor sem fio
Инструкция по монтажу и подключению / Радиоприемник
Deutsch (Originalbetriebsanleitung)
3. Mit Taster S2 den zu löschenden Kanal auswählen.
4. Mit Taster S1 das Löschen bestätigen (1 s).
5. Nach Loslassen des Tasters S1 erlischt die zugehörige Kanal LED
und die LED MD leuchtet dauerhaft.
Funktionszuweisungen des Empfängers
Folgende Funktion gilt nur für die VAL-Variante:
RF RxT SW2.4-4W-VAL 24 VAC/DC
Der auf Kanal 1 eingelernte Fußschalter bedient Relais 1 mit seinem
ersten Pedal und Relais 2 mit seinem zweiten Pedal. Das vierte Relais
schaltet das Validate Signal.
Der auf Kanal 2 eingelernte Fußschalter bedient Relais 3 mit seinem
ersten Pedal. Das vierte Relais schaltet auch hier das Validate Signal.
Wurde auf beiden Kanälen der gleiche Fußschalter eingelernt, so kann
dieser die Relais 1 bis 3 sowie Validate schalten.
Wartung
Bei rauen Betriebsbedingungen empfehlen wir eine regelmäßige
Wartung mit folgenden Schritten:
1. Prüfen der Schaltfunktion.
2. Entfernen von Schmutz.
Reinigung
- Bei feuchter Reinigung: Wasser oder milde, nicht-scheuernde,
nicht-kratzende Reinigungsmittel verwenden.
- Keine aggressiven Reinigungs- oder Lösungsmittel verwenden.
Entsorgung
- Nationale, lokale und gesetzliche Bestimmungen zur
Entsorgung beachten.
- Materialien getrennt dem Recycling zuführen.
English
Use of the mounting and wiring instructions
Target group: authorised and qualified staff.
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer.
In case of doubt, the German language version of these instructions
shall prevail.
Scope of delivery
1 device, 1 mounting and wiring instructions, carton.
Intended use
The four-channel wireless receiver is used to switch electrical loads by
means of radio transmission.
Mounting and wiring
The wireless range depends heavily on the local conditions. Conductive
materials may strongly affect the radio signal. This also includes thin
foils, e.g. aluminium laminations on insulation materials.
Antenna
Use suitable antennas only:
Device
Antenna
SW2.4
RF magnet antenna 2.4 GHz
with 1 m cable and SMA plug-in
connector
Mount the antenna on a metal plate. The metal plate serves as an
HF counterweight. Minimum size of metal plate: 250 x 250 mm.
Radio operation
The transmission is carried out at a frequency of 2.4 GHz. The
receiver can only be used in combination with the transmitter
RF GF(S)(I) SW2.4.
Assignment of the place of use:
Place of use
according to
EU
2014/53/EU (RED)
USA
FCC
Canada
IC
Design of wireless range
The radio signal is attenuated on the way from the transmitter to
the receiver. In addition, the radio signal is attenuated/influenced by
obstacles. The degree of attenuation depends on the material of the
obstacle. The following tables serve as a guide.
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Place of use
indoors
2 / 16
Mat. No.
1186917
Penetration
90...100 %
65...95 %
10...90 %
0...10 %
Wireless range (approx.)
max. 20 m
