Abus RM40Li Bedienungs-, Installations- Und Wartungsanleitung Seite 12

Device description
1
5
4
4 m

2
3

50 cm
50 cm

- 22 -
Contents
Device description ...................................................................................22
Safety information ................................................................................. 24
Putting into operation ..............................................................................27
Cleaning and disposal ............................................................................. 34
Device description, see diagram 
Item Name Comment
1 Sound outlet
The status lamp is under the cover (on the right)
2 LED status lamp
beneath the logo) and shines through it
3 Battery compartment
4 Detector base With mounting holes
Press the lower section of the housing cover
5 Test button to the actuate the test button. This button also
funtions as the mute button for the alarm tone.
Function and features
Smoke detection
Sound level
Optical alarm display
Temperature range
Humidity
Device description
Photoelectric reflection
At least 85 dB at a distance of 3 metres
LED flashes every 30 seconds, or twice
a second in the event of an alarm
0°C to +40°C
0% to 90%
