AFRISO WaterControl 01.1 Betriebsanleitung Seite 56

H
Fig. 5: Printed circuit board of the control unit
Commissioning
A B
G
A. LRNMOD key
B. LRNTEL key
C. Red LED
D. EnOcean® wireless mod-
ule
E. Separator
F. Area with DC 24 V con-
C
nections
G. Area with AC 230 V con-
D
nections
H. Transfomer
E
F
WaterControl 01.1
EN
22
