3. BUTTON PANEL CONFIGURATION WITH WIFI CONNECTION

3.1 CONNECTION AND CONFIGURATION MODE

In order to be able to access configuration of button panels Ref. 1784/3 and 1784/4, you will need a terminal
(personal computer, smartphone or tablet) capable of connecting to wireless networks.
Follow the instructions below.
Turn on the WiFi access point of the button panels (the WiFi access point is deactivated automatically).
You can proceed in two different ways:
A. Hold the program button (10) pressed for 1 second. The operations to be performed are those described in
steps B4-B12.
B. Simultaneously hold button 1
2 for button panel Ref. 1784/4 for 3 seconds.
B.1. The display shows the screen where you need to enter the password.
Ref. 1784/3
B.2. Proceed as follows to enter the password (default 1937):
1. Press button 1 repeatedly until the first digit of the password appears on the display in the box
associated with the button.
Ref. 1784/3
2. Press button 2 repeatedly until the second digit of the password appears on the display in the box
associated with the button.
Ref. 1784/3
18
and button 2 for button panel Ref. 1784/3 or button 1
Button 1
Button 2
Button 3
Button 4
Button 1
Button 2
Ref. 1784/4
Ref. 1784/4
Ref. 1784/4
and button
Button 1
Button 2
Button 3
Button 4
Button 1
Button 2
