Service And Warranty - Dremel Multi-Max MM20 Bersetzung Der Original Bedienungsanleitung

accessory
Smaller cuts and flush cuts.
Example: Cut-outs in furniture for cable
WOOD
MM411 connections.
Cutting and deep flush cuts; also for sawing
close to edges, in corners and hard to reach
areas.
MM470
Example: Flush cutting door jamb or window
sill, for flooring or tile installation.
Smaller cuts and plunge cuts.
Example: Sawing off water pipes (copper)
or cable ducts flush against walls, floors or
MM422
ceilings.
Cutting in existing trim or flooring. Cutting
close to edges in corners or hard to reach
WOOD
areas. Examples: Installing floor vent or
MM450
repairing damaged wood flooring.
Removing grout from between wall or floor
tiles.
Example: Removing grout joints between
wall tiles for repair work.
MM501
Remove vinyl flooring and bonded carpeting.
Example: On stairs/steps or other small/
medium sized surfaces.
Scraping off old coats of varnish/paint or
MM600
other adhesive.
Removing thinset or cement.
Example: Grinding away thinset after tile
removal. Removing paint or oil stains from
cement.
MM900
switch setting
2
4
6
8
10
Operating Principle
Due to the oscillating drive the application tool/accessory swings
up to 21000 times per minute for 3.0°. This allows for precise
work in narrow spaces.
sawing
• use undamaged faultless saw blades only. Deformed,
blunt saw blades or saw blades that are otherwise damaged
can break.
• when sawing light building materials, observe the
statutory provisions and the recommendations of the
material suppliers.
• Plunge cuts may only be applied to soft materials, such
as wood, gypsum plaster boards, etc.!
Before sawing with HCS saw blades in wood, particle board,
building materials, etc., check these for foreign objects such as
nails, screws, or similar. If required, remove foreign objects or use
BIM saw blades.
application
speed range/min (OPM)
10,000-11,000
11,000-13,000
13,000-16,000
16,000-19,000
19,000-21,000
separating
Note: When separating wall tiles take into consideration that the
application tools/accessories wear heavily when used for longer
periods of time.
scraping
For scraping, select a high oscillation rate.
Work on a soft surface (e.g. wood) at a flat ange, and apply only
light pressure. Otherwise the scraper can cut into the surface.
MaintEnancE
Preventive maintenance performed by unauthorized personnel
may result in misplacing of internal wiring and components which
could cause serious hazard. We recommend that all tool service
be performed by a Dremel Service Facility. To avoid injury from
unexpected starting or electrical shock, always remove plug from
wall outlet before performing service or cleaning.
tO aVOiD acciDEnts, alwaYs
WARNING
!
DiscOnnEct tHE tOOl anD/Or
cHargEr frOM tHE POwEr suPPlY BEfOrE clEaning. The
tool can be cleaned most effectively with compressed dry air. Always
wear safety goggles when cleaning tools with compressed air.
Ventilation openings and switch levers must be kept clean and
free of foreign matter. Do not attempt to clean the tool by inserting
pointed objects through an opening.
cErtain clEaning agEnts anD
WARNING
!
sOlVEnts DaMagE Plastic Parts.
Some of these are: gasoline, carbon tetrachloride, chlorinated
cleaning solvents, ammonia and household detergents that contain
ammonia.

sErVicE anD warrantY

nO usEr sErVicEaBlE Parts insiDE.
WARNING
!
Preventive maintenance performed by
unauthorized personnel may result in incorrect connection of internal
wiring and components which could cause serious hazard. We
recommend that all tool service be performed by a Dremel Service
Centre. SERVICEMEN: Disconnect the tool and/or charger from the
power source before servicing.
This DREMEL product is guaranteed in accordance with statutory/
country-specific regulations; damage due to normal wear and tear,
overload or improper handling are excluded from the warranty.
In case of a complaint, send the undismantled tool or charger and
proof of purchase to your dealer.
cOntact DrEMEl
For more information on the Dremel product range, support and
hotline, go to www.dremel.com.
12
clEaning
