System Map: Front, Rear, Bot tom & Top Views
2
1
3
5
6
7
8
If your purchase includes the docking station, align the markers
case of the computer with that on the docking station before docking (see the
accompanying docking station for full details of the docking procedure). If your
purchase does not include the docking station, the marker will still appear on
the computer's top case but may be disregarded.
Front
3
Rear
4
5
5
5
8

Docking
10
9
Use the WLAN Switch (for Wireless LAN
9
on the top
only) to toggle power to the WLAN mod-
ule. The position of the WLAN switch
governs the power status of the WLAN
module at startup, and upon resuming
from a power saving state.
Figure 3
Front, Rear, Bottom & Top
Views (Top View with Op-
tional Docking Station)
1. LED Indicators
2. WLAN Switch
3. Battery
4. Docking Port
5. Vent
6. Component Bay Cover
7. Drainage Outlet
8. Speakers
9. Alignment Markers
10. Docking Station
(Optional)

WLAN Switch
7
