MAXDATA M-BOOK 600 Benutzerhandbuch Seite 21

Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
Security
BIOS Password
Security (Kensington® Type) Lock Slot
Fingerprint Reader
TPM v1.2
Intel vPro (Model B only)
Keyboard
Isolated A4 Size Keyboard with Anti-Spray
Support
Interface
One Powered USB 2 .0 Port (see
Two USB 3.0 Ports
One eSATA/USB 2.0 Combo Port
One HDMI-Out Port
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One External Monitor Port
One ExpressCard/34(54) Slot
One DC-in Jack
(Factory Option) One Docking Port
Pointing Device
Built-in Touchpad (scrolling key functionality
integrated)
18
Communication
Built-In Gigabit Ethernet LAN
(Factory Option) 1.3M Pixel USB PC Cam-
era Module
(Factory Option) 3.75G/HSPA Mini-Card
Module
WLAN/ Bluetooth Half Mini-Card
Modules:
Model A:
(Factory Option) Intel® Centrino®
Advanced-N 6230 Wireless LAN (802.11a/g/
n) + Bluetooth 3.0
(Factory Option) Intel® Centrino® Wireless-
N 1030 Wireless LAN (802.11b/g/n) + Blue-
tooth 3.0
(Factory Option) Intel® Centrino® Wireless-
page 8)
N 1000 Wireless LAN (802.11b/g/n)
(Factory Option) Third-Party Wireless LAN
(802.11b/g/n) + Bluetooth 3.0
(Factory Option) Third-Party Wireless LAN
(802.11b/g/n)
Model B:
(Factory Option) Intel® Centrino®
Advanced-N 6230 Wireless LAN (802.11a/g/
n) + Bluetooth 3.0
Card Reader
Embedded Multi-in-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/
SDXC
MS (Memory Stick) / MS Pro / MS Duo
Mini Card Slots
Slot 1 for WLAN Module or WLAN and
Bluetooth Combo Module
(Factory Option) Slot 2 for 3.75G/HSPA
Module
Environmental Spec
Temperature
° °
Operating: 5 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 3.42A or 18.5V, 3.5A (65W)
6 Cell Smart Lithium-Ion Battery Pack,
62.16WH
Dimensions & Weight
330mm (w) * 225mm (d) * 24.5 - 32mm (h)
1.78kg with ODD & 62.16WH Battery
