Gamme Silensys® | Silensys® range | Baureihe Silensys® | Gama Silensys® |
Taille Fluide frigorigène
Size Refrigerant
Größe Kältemittel
Tamaño Fluido frigorígeno
Dimensione Fluido frigorigeno
Размер Хладагент
Wielkość
Czynnik chłodniczy
S R-452A / R-404A
S R-452A / R-404A
S R-452A / R-404A
S R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
XL R-452A / R-404A
XL R-452A / R-404A
XL R-452A / R-404A
S R-452A / R-404A
S R-452A / R-404A
S R-452A / R-404A
S R-452A / R-404A
S R-452A / R-404A
S R-452A / R-404A
S R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
M R-452A / R-404A
L R-452A / R-404A
L R-452A / R-404A
L R-452A / R-404A
L R-452A / R-404A
L R-452A / R-404A
L R-452A / R-404A
XL R-452A / R-404A
XL R-452A / R-404A
XL R-452A / R-404A
* Vitesse max. - Max speed - Max. Drehgeschwindigkeit - Velocidad máx. - Velocità massima - Скорость макс - Prędkość maks.
Gamma Silensys® | модельный ряд Silensys® | Seria Silensys®
Applications Modèles Débit d'air*
Application Models Air flow*
Anwendung Modelle Luftvolu-
Aplicación Modelos menstrom*
Applicazione Modelli Caudal
оборудование модель de aire*
Zastosowania Modele Debito
d'aria*
Расход*
Wydatek
powietrza*
[m 3 /h]
LBP SILAJ2432Z 1650
LBP SILAJ2440Z 1650
LBP SILAJ2446Z 1650
LBP SILAJ2464Z 1650
LBP SILFH2480Z 1650
LBP SILFH2480Z 1650
LBP SILFH2511Z 2700
LBP SILFH2511Z 2700
LBP SILAG2513Z 2700
LBP SILAG2516Z 2700
LBP SILAG2519Z 2700
LBP SILAG2522Z 2700
LBP SILAG2525Z 2700
LBP SILAGD2532Z 6600
LBP SILSH2534Z 6600
LBP SILAGD2544Z 6600
HBP SILAE4450Z 1650
HBP SILAE4460Z 1650
HBP SILAJ9480Z 1650
HBP SILAJ9510Z 1650
HBP SILAJ9513Z 1650
HBP SILAJ4517Z 1650
HBP SILAJ4519Z 1650
HBP SILFH4524Z 2700
HBP SILFH4524Z 2700
HBP SILFH4532Z 2700
HBP SILFH4532Z 2700
HBP SILFH4538Z 2700
HBP SILFH4540Z 2700
HBP SILAG4546Z 5400
HBP SILAG4553Z 5400
HBP SILAG4561Z 5400
HBP SILAG4568Z 5400
HBP SILAG4573Z 5400
HBP SILAG4581Z 5400
HBP SILAGD4590Z 6600
HBP SILSH4591Z 6600
HBP SILAGD4610Z 6600
Ø Aspiration Ø Départ liquide
Ø Suction Ø Liquid exit
Ø Saugseite Ø Druckseite
Ø Aspiración Ø Salida de líquido
Ø Aspirazione Ø Partenza liquido
Ø всасывание Ø жидкостная линия
Ø Zasysania Ø Wylotu czynnika
[in] [mm] [in] [mm]
1/2 12.7 1/4 6.35
1/2 12.7 1/4 6.35
1/2 12.7 3/8 9.5
5/8 15.9 3/8 9.5
5/8 15.9 3/8 9.5
5/8 15.9 3/8 9.5
5/8 15.9 3/8 9.5
5/8 15.9 3/8 9.5
7/8 22.2 3/8 9.5
7/8 22.2 3/8 9.5
7/8 22.2 3/8 9.5
7/8 22.2 3/8 9.5
7/8 22.2 3/8 9.5
11/8 28.6 5/8 15.9
13/8 34.9 5/8 15.9
11/8 28.6 5/8 15.9
3/8 9.5 1/4 6.35
3/8 9.5 1/4 6.35
1/2 12.7 3/8 9.5
5/8 15.9 3/8 9.5
5/8 15.9 3/8 9.5
5/8 15.9 3/8 9.5
5/8 15.9 3/8 9.5
5/8 15.9 3/8 9.5
5/8 15.9 3/8 9.5
7/8 22.2 1/2 12.7
7/8 22.2 1/2 12.7
7/8 22.2 1/2 12.7
7/8 22.2 1/2 12.7
7/8 22.2 5/8 15.9
7/8 22.2 5/8 15.9
11/8 28.6 5/8 15.9
11/8 28.6 5/8 15.9
11/8 28.6 5/8 15.9
11/8 28.6 5/8 15.9
11/8 28.6 5/8 15.9
11/8 28.6 5/8 15.9
11/8 28.6 5/8 15.9
ANNEXE
1
Pressostat
Poids Poids
Weight emballé (coupure-enclenchement)
Pressure switch
Gewicht (carton +
(Cut for the pressure switch)
Peso palette)
(Engage)
Peso Packed
Pressostat
Вес. weight
(Ausschalten - Einschalten)
Pesostato
(carton +
Masa
(Corte - Conexión)
pallet)
Pressostato
Masa w
(Interruzzione - Avviamento)
opakowaniu
Отключение
(karton +
(для реле давления - Включение)
Presostat
paleta)
(odcięcie-włączenie)
[Kg] [Kg] HBP [bar] LBP [bar]
67 87 29.7 - 25.7 0.3 - 1.1
68 88 29.7 - 25.7 0.3 - 1.1
69 89 29.7 - 25.7 0.3 - 1.1
72 92 29.7 - 25.7 0.3 - 1.1
76 98 29.7 - 25.7 0.3 - 1.1
84 106 29.7 - 25.7 0.3 - 1.1
79 101 29.7 - 25.7 0.3 - 1.1
86 108 29.7 - 25.7 0.3 - 1.1
103 125 29.7 - 25.7 0.3 - 1.1
108 130 29.7 - 25.7 0.3 - 1.1
108 130 29.7 - 25.7 0.3 - 1.1
112 135 29.7 - 25.7 0.3 - 1.1
112 135 29.7 - 25.7 0.3 - 1.1
243 262 29.7 - 25.7 0.3 - 1.1
257 276 29.7 - 25.7 0.3 - 1.1
259 278 29.7 - 25.7 0.3 - 1.1
59 79 29.7 - 25.7 2.7 - 4.2
59 79 29.7 - 25.7 2.7 - 4.2
68 88 29.7 - 25.7 2.7 - 4.2
69 89 29.7 - 25.7 2.7 - 4.2
71 91 29.7 - 25.7 2.7 - 4.2
70 90 29.7 - 25.7 2.7 - 4.2
71 91 29.7 - 25.7 2.7 - 4.2
78 100 29.7 - 25.7 2.7 - 4.2
83 106 29.7 - 25.7 2.7 - 4.2
80 102 29.7 - 25.7 2.7 - 4.2
87 109 29.7 - 25.7 2.7 - 4.2
80 102 29.7 - 25.7 2.7 - 4.2
87 109 29.7 - 25.7 2.7 - 4.2
128 143 29.7 - 25.7 2.7 - 4.2
134 149 29.7 - 25.7 2.7 - 4.2
134 149 29.7 - 25.7 2.7 - 4.2
138 153 29.7 - 25.7 2.7 - 4.2
139 154 29.7 - 25.7 2.7 - 4.2
151 166 29.7 - 25.7 2.7 - 4.2
253 272 29.7 - 25.7 2.7 - 4.2
251 270 29.7 - 25.7 2.7 - 4.2
256 275 29.7 - 25.7 2.7 - 4.2
366473_b / 09/2019 33
