General system information

4 General system information
This device is part of the Homematic IP smart home sys-
tem and works with the Homematic IP radio protocol. All
Homematic IP devices can be configured comfortably
and individually with a smartphone via the Homematic IP
app. The available functions provided by the Homemat-
ic IP system in combination with other components are
described in the Homematic IP User Guide. All current
technical documents and updates are provided at www.
eQ-3.de.
5

Mounting

You can flexibly mount the floor heating actuator to a
wall using the supplied screws or to a DIN rail.
5.1

Screw mounting

For mounting the floor heating actuator using screws,
please proceed as follows:
• Please select a suitable mounting location close
to your heating manifold.
Make sure that no electricity or similar lines run in
the wall at this location!
• Use a pen to mark the positions of the two bore
holes with a distance of 13.6 cm on the wall (see
52
