4. Symbols Description

Compliance with EU directives
Attention laser radiation!
Risk of Danger. Important information See instruction
manual
This product should not be disposed along with normal
domestic waste at the end of its service life but should be
handed over at a collection point for recycling electrical and
electronic devices.
connection 6V DC
Battery compartment

5. Controls

Note Fig. 1
1. Display
2. Function keys (meaning see below.)
3. Laser optics
4. Optic converter
5. Measuring adapter (2 piece)
6. Reference wheel
7. connection 6V DC
