8 Adjusting the Lawn Mower for the User

8 Adjusting the Lawn Mower for the User
8.1

Folding Up the Handlebar

► Stop the engine.
► Detach the spark plug socket.
► Place the lawn mower on a level surface.
► Loosen star grips nuts (1) if they are tightened.
► Fold up handlebar (2), ensuring that cable (3) is not
trapped.
0478-111-9647-A
► Firmly tighten star grip nuts (1).
Handlebar (2) is firmly attached to the lawn mower.
► Press control bar for mowing (4) to handlebar (2) and
hold.
► Slowly pull starter handle (5) in the direction of starter
rope guide (6).
► Hook starter handle (5) into starter rope guide (6).
► Release control bar for mowing (4).
► Re-attach the spark plug socket.
8.2

Folding the Handlebar

The handlebar can be folded for space-saving transport or
storage.
► Stop the engine.
► Detach the spark plug socket.
► Place the lawn mower on a level surface.
► Press the control bar for mowing to the handlebar and
hold.
► Detach the starter handle from the starter rope guide and
slowly guide back towards the engine.
► Release the control bar for mowing.
► Hold the handlebar and loosen the star grip nuts.
► Fold down the handlebar forwards.
