Empasa Start Montageanleitung Seite 12

Assembly
Risk of injury
6
Cut the overlapping fabric
Caution! Fabric A can be damaged irreversibly if utility knife
slips!
Risk of injury
X + 1 mm
F G
8
Transfer the width X of the window frame on the hang-on
brackets F and G . Measured from the bending edge along
the long side. Grasp the hang-on brackets
tongs on the mark, just so it is visible. Bend the end of the
long side in opposite of the short side at 90 degrees with
your hand. The distance between both sides has to be at least
as long as the width X of the window frame.
10
Hang the insect screen on the window.
EP01043
A
A .
Finished view
X + 1 mm
F and G
7
Measure the width X of the window frame where the insect
screen should be placed and note the result.
9
Attach hang-on brackets
to the clamping rails
with
time the lower bend of the hang-on brackets
lying flush with the top edge of the clamping rails
width profiles
11
General view.
12
min. 5 mm
max. 35 mm
x cm
F G
I
I
E
E
F and G with cross-head screws I
E for the height profiles
I
B . At the same
F and G is
E for the
V1/2019-10161
