Overview of parts

A
F
Name (interior view)
A Fabric
B Height profile (long)
C Width profile (short)
D Connectors
E
Clamping rails
F Hang-on brackets (long side)
G Hang-on brackets (short side)
H Handle
I Cross-head screw
Legend:
For missing parts, always have the highlighted part number or the part
letter prepared.
Example: Handle I-13003 - 0 10
reference no.

Taking measurements

H= Height cm
W = Width
EP01043
B
G
Numer
1 x
2 x
2 x
4 x
4 x
2 x
2 x
2 x
8 x
o Handle H
H
cm
W
C
H
Part no.
S-0097
I-14003-002
I-14003-002
I-14003-004
S-0017
EM00024-0003
EM00024-0004
I-13003-010
I-14003-007
Measure between inner edges of window frame (dimension of
opening) and write down the result.
Caution: With chamfered window frames always measure from
the outmost edge.
Hint:
The measured light dimension does not correspond to the outer
frame dimension of the finished insect protection kit.
The finished outer frame dimension of the insect screen kit is
larger by the contact area than the measured light dimension
(see also page 9 under point assembly Instructions).
10
Kit-No. EP01043
D
E
I
V1/2019-10161
