Mount your clip-on thermal device VIPER in front of the dayti me rifl e scope as follows:
1 1
Turn the adapter ring 2 clockwise and screw it into the thread 1 , located on Turn the adapter ring 2 clockwise and screw it into the thread 1 , located on
the back side of the device unti l stops. the back side of the device unti l stops.
2 2
Turn the fi xed adapter ring 3 clockwise and screw it on the inner thread of Turn the fi xed adapter ring 3 clockwise and screw it on the inner thread of Turn the fi xed adapter ring 3 clockwise and screw it on the inner thread of
the adapter ring 2 . the adapter ring 2 .
3 3
Positi on the clip-on thermal device VIPER to the dayti me rifl e scope with the
control butt ons located on top.
Put the clip-on thermal device VIPER with the fi xed adapter on the front of the
dayti me rifl e scope 4 and fi x it with the adapter thumb 5 . dayti me rifl e scope 4 and fi x it with the adapter thumb 5 .
