1.4 Type designation

The type code contains all factory-configured settings of the analogue inputs
(1), the outputs (2), and the supply (3). The supply voltage connected must
correspond to the voltage shown on the label. The label is affixed to the hou-
sing.
704010/0- ... - ... - ..
(1) Analogue inputs
Standard version .................................................................... 888
Measurement input
Pt 100 resistance thermometer
Thermocouples
Fe-Con L
Fe-Con J
NiCr-Ni K
Cu-Con U
Cu-Con T
NiCrSi-NiSi N
Pt10Rh-Pt S
Pt13Rh-Pt R
Pt30Rh-Pt6Rh B
Standard signals
10 —
–50 to +50 mV
0.2 —
–1 to
–10 to +10
Potentiometer 50 — 10 000Ω
Resistance 0 — 400Ω
AC current 0 — 50mA
Special version ....................................................................... 999
Factory-configured to customer specification.
X = factory-set, freely programmable
All manuals and user guides at all-guides.com
(1) (2) (3)
0 — 50 mV
50 mV
0 — 1 V
1 V
+1 V
0 — 10 V
2 — 10 V
V
0 — 20 mA
4 — 20 mA
1 Introduction
Inputs
1 2
X X
