Always attach the transport guard straight away.

6. Technical data

MFH3300-4P
Technical data
Cutting data grass trimmer
Cutting circle diameter of line
Cutting line diameter
Cutting line length
Maximum speed grass trimmer
Cutting data brush cutter
Cutting circle diameter of blade
Cutter balde thickness
Teeth quantity
Maximum speed brush cutter
Cutting data hedge trimmer
Cutting circle diameter
Angle adjustment
Cutting length
Max. cutting speed max.
Cutting data pole saw
Guide bar length
Cutting length
Guide bar type
Chain pitch
Saw chain type
Chain link thickness
Oil tank capacity
Power unit
Displacement
Max. engine output
Idle speed
Fuel tank capacity
Engine type
Weight grass trimmer
Weight brush cutter
Weight pole saw
Weight hedge trimmer
Subject to technical changes!
Information concerning noise emission measured ac-
cording to relevant standards:
Sound pressure L = 94 dB(A)
pA
Sound power L = 114 dB(A)
WA
Uncertainty K = 3 dB(A)
PA
Wear ear­muffs.
The impact of noise can cause damage to hearing.
Grass trimmer: vibration A
hv
Brush cutter: vibration A
hv
Hedge trimmer: vibration A
hv
Pole saw: vibration A
hv
Uncertainty K
PA
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
430 mm
2 x 2.4 mm
4 m
7000
min
-1
255 mm
1.4 mm
3
8500
min
-1
24 mm
+90°/0°/­75° (165°)
400 mm
1550
min
-1
305 mm
254 mm
AL10­39­507P
3/8"
3/8.50­39
1.27 mm
125
cm
3
32.6
cm
3
0,9
kW
3000 ±200
min
-1
0,9 l
2­stroke engine, air­
cooled
7.2 kg
7.2 kg
7.1 kg
7.7 kg
= 4,8 m/s
2
= 4,12 m/s
2
= 4,77 m/s
2
= 4,32 m/s
2
= 1,5 m/s
2
Reduce noise generation and vibration to a minimum!
• Use only equipment that is in perfect condition.
• Maintain and clean the equipment regularly.
• Adopt your way of working to the equipment.
• Do not overload the equipment.
• Have the equipment checked if necessary.
• Switch off the equipment when not in use.
• Wear gloves.
In these operating instructions we have marked
the places that have to do with your safety with
this sign: m

7. Before starting the equipment

Each time before use, check the following:
• That there are no leaks in the fuel system.
• That the equipment is in perfect condition and that
the safety devices and cutting devices are com-
plete.
• That all screws are securely fastened.
• That all moving parts move smoothly.
Fuel and oil
Recommended fuels
Use only a mixture of unleaded petrol and special
2­stroke engine oil. Mix the fuel mixture as indicated
in the fuel mixing table.
Important: Do not use a fuel mixture which has
been stored for longer than 90 days.
Important: Never use 2­stroke oil with a recom-
mended mixing ratio of 100:1. The manufacturer's
warranty will be voided in case of engine damage
due to inadequate lubrication.
Important: Only use containers designed and ap-
proved for the purpose to transport and store fuel.
Pour the correct quantities of petrol and 2­stroke oil
into the mixing bottle (see scale printed on the bot-
tle). Then shake the bottle well.
Never use oil for 4-cycle engine or use water cooled
2­cycle engine. It can cause spark plug fouling ex-
haust part blocking or piston ring sticking.
Mixed fuels, which have been left unused for a pe-
riod of one month or more, may clog the carburetor
or result in the engine foiling to operate property. Put
remained fuel into an airtight container and keep it in
the dark and cool room.
Fuel mixing table
Mixing procedure: 40 parts petrol to 1 part oil
Example:
1 l Petrol : 0,025 l 2­stroke oil
5 l Petrol : 0,125 l 2­stroke oil
